Flexible Logistics Delivery
The range-extended van customized and developed by GETEC is equipped with its self-developed range extension system and a complete set of electric drive system and vehicle control units. It has a longer driving range and lower operating costs. It is applicable to urban and inter-city logistics distribution.
Features
Max. Range (WLTC)：660+km
Max. Capacity：7+m³
Fuel Tank Capacity：40L
Battery Mode：Fast Charging
Advantages
The range extender system, composed of three core components developed by GETEC, is adaptable to various of chassis platforms. It aims to create a “light-duty and high-efficiency drivetrain system” characterized by higher efficiency, lower fuel consumption and longer driving range.
Parameters
| Vehicle Parameter | |
| Wheelbase | 2890 mm |
| Vehicle size L×W×H | 5300×1700×2250 mm |
| Cargo Size L×W×H | 2650×1360×2500 mm |
| Cargo Capacity | 7.2+ m³ |
| Overall Mass | 3060 kg |
| Curb Mass | 1960 kg |
| Max. Speed | 80 km/h |
| Max. Range (WLTC) | 660+ km |
| Range Extender System | |
| Motor | Type:PMSM |
| Peak Power:80kW | |
| Engine:4-cylinder,1.4L | |
| Range Extender | Generator:GETEC -40℃~+185℃ water-cooled generator |
| Fuel Tank:High pressure fuel tank | |
| Controller | Vehicle Control Unit:GETEC VCU |
| All-in-one Control Unit:Espiritek | |
| Battery | Battery Type:CATL LFP Battery |
| Battery Capacity:42 kWh | |
| Charging Mode:Fast Charging | |
| Chassis | |
| Brake | Front disc rear drum |
| Suspension | Torsion bar spring independent suspension/steel spring non-independent suspension |
| Tires | 195R15LT Steel |
| Configuration | |
| Standard | All-inclusive cab, fast charging, standard comfort seats, USB power, 7-inch color LCD combination instrumentation, low-speed pedestrian alarm reminder, maintenance-free battery, ABS, T-BOX (new energy), front fog lights + cornering auxiliary lighting. |
| Optional | Aluminum alloy rims, 8-inch HD touch screen + reverse camera, daytime running lights, widened rearview mirror. |
*The specific parameters are subject to the vehicle announcement
